DK7763F EDM wire cutting machine https://www.ruitewedm.com/DK7763F-taper.html The DK7763F CNC wire cutting machine is a high performance product from Ruite. The machine uses advanced CNC technology to accurately cut a variety of materials, both metallic and non-metallic. It features high precision, high efficiency and stability, making it suitable for a wide range of industrial processing needs. Worktable Travel(Mm):630*1000 Worktable Size(Mm):1350*750 Max. Cutting Thickness(Mm):700 Max. Load(Kg):1200 Dimensions(Mm):2250*1850*2050 Weight(Kg):2800

VMC 1166 CNC Vertical Machining Center https://www.josencnc.com/VMC-1166-CNC-Vertical-Machining-Center.html 1.This model is suitable for communication electronics, automobile and locomotive parts production, and automated parts processing. 2.Combined with FEM analysis, the main components of the base, column and saddle all adopt unique high rigidity structure, which makes the internal force structure of the whole machine more optimized and ensures the rigidity and thermal variation stability of the whole machine. 3.Three axes linear precision rolling guide design, fast acceleration and deceleration response, effectively improve the machining efficiency and machining accuracy of the machine, even under heavy load is also excellent. 4.The front end of the spindle is equipped with a circular water jet to allow effective cooling of the cutting tool, while the internal air curtain with negative pressure extends the service life and ensures reliable use of the spindle for long time and high-speed operation. 5.The stable base and column with lightweight motion axis components effectively ensure the stability of the machine during high acceleration and deceleration movements. DV-1166 X-axis travel 1100mm Y-axis travel 620mm Z-axis travel 600mm Working table size (X*Y) 1200x600mm Max.loading capacity of working table 900kg Table T-slot size (width * number of slots * spacing) 18x5x100number Spindle speed 10000rpm Spindle drive form belt driven Spindle power BT40:11/15kW Spindle bore specification BT40 Distance from spindle to table surface BT40:125-725mm Rapid feed rate(X,Y,Z) 36/36/36m/min Cutting feed rate 10000mm/min Tool magazine capacity cutter arm type 24 Tool diameter/adjacent tool space BT40:Φ80/Φ150 Max. Tool length 300 mm Max. Tool weight BT40:8kg Positioning accuracy ±0.005mm Reproduction accuracy ±0.003mm Controller 0i-MF/M80 Air pressure demand 6kg/cm2 Power demand 30kVA Machine weight 6.5T A B C D E F G H I J K T-slot number 1200 600 100 100 100 100 100 18 31 13 30 5 DV-1166B X-axis travel 1100mm Y-axis travel 620mm Z-axis travel 600mm Working table size (X*Y) 1200x600mm Max.loading capacity of working table 900kg Table T-slot size (width * number of slots * spacing) 18x5x100number Spindle speed 8000rpm Spindle drive form belt driven Spindle power BT50:15/18.5 Spindle bore specification BT50 Distance from spindle to table surface BT50:145-745 Rapid feed rate(X,Y,Z) 36/36/36m/min Cutting feed rate 10000mm/min Tool magazine capacity cutter arm type 24 Tool diameter/adjacent tool space BT50:Φ110/Φ200 Max. Tool length 300 mm Max. Tool weight BT40:15kg Positioning accuracy ±0.005mm Reproduction accuracy ±0.003mm Controller 0i-MF/M80 Air pressure demand 6kg/cm2 Power demand 30kVA Machine weight 6.5T A B C D E F G H I J K T-slot number 1200 600 100 100 100 100 100 18 31 13 30 5
